Cat Product Link

Articulated Truck Bare Chassis

Cat® bare chassis articulated trucks provide the custom solution for specialized applications such as water trucks, high capacity waste haulers, and fuel / lube trucks using the proven components of Cat articulated trucks and the support of Caterpillar and your Cat dealer.

Model	Standard Wheel Base	Long Wheel Base	Rated Payload
735C Bare Chassis	162.4 in / 4126 mm	228.4 in / 5801 mm	36 t / 32.7 t

Off-Highway Trucks Bare Chassis

Cat® bare chassis off-highway trucks provide the custom solution for specialized applications such as water trucks using the proven components of Cat off-highway trucks and the support of Caterpillar and your Cat dealer.

Model	LRC Bare Chassis Weight without Hoist	Tractor ROPS	Nominal Water Tank Capacity
770G Bare Chassis	54357 lb / 24656 kg	77430 lb / 35122 kg	9000 gal (US) / 34000 l

Demolition Excavators

Cat® demolition excavators are purpose built for the rigor of demolition applications. With specialized cabs, straight boom and ultra high reach configurations, and a full line of matching demolition attachments, Cat demolition excavators are ready to help you tear through your next job.

Model	Engine Model	Stroke	Net Flywheel Power
336F L Straight Boom (2017)	Cat C9.3 ACERT	5.87 in / 149 mm	306 HP / 228 kW

Track Asphalt Pavers

Track-equipped asphalt pavers offer superior traction for jobs that require wide pulls or large mix-delivery vehicles.

Model	Gross Power	Standard Paving Range	Operating Weight - With SE34 VT
AP355F	74.8 HP / 55 kW	1.75-3.42 m (5' 9" - 11' 2")	19246 lb / 8730 kg

Wheel Excavators

Cat® wheeled excavators have the mobility, speed, power, and reliability to be the most versatile machine in your fleet. They help you take on a variety of challenges every day, and at a lower cost.

Model	Engine Model	Net Power	Maximum Travel Speed
M314F (2017)	Cat C4.4	141 HP / 105 kW	23 mile/h / 37 km/h
M316F (2017)	Cat C4.4	141 HP / 105 kW	22 mile/h / 35 km/h
M318F (2017)	Cat C7.1	169 HP / 126 kW	22 mile/h / 35 km/h

Small Excavators

Cat small excavators are perfect for smaller jobs and applications with space constraints. Powered by fuel-efficient engines and advanced hydraulic systems, our small excavators offer exclusive Cat technology and a variety of matching Cat attachments to help you complete your work on time at a low cost per hour.

Model	Net Power - ISO 9249	Operating Weight	Maximum Digging Depth
313F L	92 HP / 68 kW	33080 lb / 15000 kg	19.8 ft / 6040 mm
315F L	97 HP / 72 kW	37794 lb / 17140 kg	19.5 ft / 5950 mm
313 GC	73 HP / 54.3 kW	30400 lb / 13800 kg	19.8 ft / 6040 mm
313	108 HP / 80.9 kW	30400 lb / 13800 kg	19.8 ft / 6040 mm
315	108 HP / 80.9 kW	34000 lb / 15400 kg	19.6 ft / 5990 mm

Telehandlers

Telehandlers from Caterpillar

Model	Rated Load Capacity	Maximum Lift Height	Engine Model
TL1255D	12000 lb / 5443 kg	54.6 ft / 16600 mm	Cat® C4.4 ACERT™*

Three Axle Articulated Trucks

Cat® articulated trucks haul a wide spectrum of material in a variety of applications and ground conditions. Simple operation and automotive style comfort along with combined service points and extended service intervals mean these dump trucks let you focus on your work spending less time and money on servicing.

Model	Engine Model	Rated Payload	Heaped (SAE 2:1)
725C2	Cat C9.3	26.5 ton (US) / 24 ton (US)	19.6 yd³ / 15 m³
730C2 EJ	Cat® C13 ACERT™	31 t / 28 t	22.1 yd³ / 16.9 m³
725	Cat C9.3	26.5 ton (US) / 24 t	19.6 yd³ / 15 m³
740 EJ	Cat® C18	42 ton (US) / 38 t	30.1 yd³ / 23 m³
745	Cat C18	45.2 t / 41 t	32.7 yd³ / 25 m³
735C	Cat C15 ACERT	36 t / 32.7 t	26.8 yd³ / 20.5 m³
730C2	Cat C13 ACERT	31 t / 28 ton (US)	23 yd³ / 17.5 m³

Landfill Compactors

Cat® landfill compactors have enhanced features with additional guarding and attention to placement of components to ensure you get the most durable landfill compactor.

Model	Operating Weight	Gross Power	Net Power
826K	90207 lb / 40917 kg	435 HP / 324 kW	405 HP / 302 kW
836K	123319 lb / 55927 kg	562 HP / 419 kW	496 HP / 370 kW

Soil Compactors

The purpose built Cat® four wheel drive soil compactors maximize soil density through a tamping wheel tip design, machine weight impact and higher speeds for greater penetration.

Model	Engine Model	Net Power	Operating Weight
825K	C15 Cat®	405 HP / 302 kW	78326 lb / 35528 kg

Tandem Vibratory Rollers

Cat Tandem Vibratory Rollers are available in a range of sizes and configurations to meet any application. Large double-drums are simple to set up for maximum compaction efficiency on any type of mix.

Model	Operating Weight - With ROPS/FOPS	Standard Compaction Width	Gross Power
CCS9 Combination Asphalt Compactor	19842 lb / 9000 kg	84 in / 2134 mm	131 HP / 98 kW

Pneumatic Rollers

Cat Pneumatic Rollers are ideal for applications like wear courses and binder courses as well as compaction of natural soils and materials with lime or cement.

Model
CW34
CW16 9-Wheel
CW16 11-Wheel

Vibratory Soil Compactors

Cat Vibratory Soil Compactors are durable and reliable. They offer high compaction performance, speed and gradeability to maximize productivity on a wide range of applications.

Model	Compaction Width	Gross Power
CS34	50 in / 1270 mm	74 HP / 55 kW
CP44B	66 in / 1676 mm	100.6 HP / 75 kW
CS44B	66 in / 1676 mm	100.6 HP / 75 kW
CP54B	84 in / 2134 mm	131 HP / 98 kW
CS54B	84 in / 2134 mm	131 HP / 98 kW
CP56B	84 in / 2134 mm	157 HP / 117 kW
CS56B	84 in / 2134 mm	157 HP / 117 kW
CS64B	84 in / 2134 mm	131 HP / 98 kW
CP68B	84 in / 2134 mm	157 HP / 117 kW
CS68B	84 in / 2134 mm	157 HP / 117 kW
CP74B	84 in / 2134 mm	173.7 HP / 129.5 kW
CS74B	84 in / 2134 mm	173.7 HP / 129.5 kW
CS78B	84 in / 2134 mm	173.7 HP / 129.5 kW

Large Excavators

Their power, speed, and fuel efficiency make Cat® large excavators the right machine for bulk excavation applications. With powerful, yet efficient engines, advanced hydraulic systems, factory equipped technology, and matching attachments, these machines will help you complete your large-scale projects on time and within budget.

Model	Net Power - ISO 9249	Operating Weight	Maximum Digging Depth
374 - Tier 4	484 HP / 361 kW	158200 lb / 71700 kg	28.1 ft / 8570 mm
349	424 HP / 316 kW	105200 lb / 47700 kg	25.1 ft / 7660 mm
352	443 HP / 330 kW	111300 lb / 50500 kg	26.11 ft / 8210 mm

Off-Highway Trucks

For over 50 years, rugged Cat® off-highway trucks and mining trucks have worked in the harsh conditions of mines, construction projects and quarries around the world. Pass-matched with our wheel loaders and excavators, you can count on our haul trucks for maximum productivity at a low cost per ton.

Model	Nominal Payload Class (100%)	Engine Model	Top Speed - Loaded
770G	42.1 ton (US) / 38.2 t	Cat® C15	45.8 mile/h / 73.7 km/h
772G	51.6 ton (US) / 46.8 t	Cat® C18	49.2 mile/h / 79.2 km/h
773G	61 ton (US) / 55.3 t	Cat® C27	41.6 mile/h / 66.9 km/h
775G	70.5 ton (US) / 64 t	Cat® C27	41.6 mile/h / 66.9 km/h

Wheel Asphalt Pavers

Wheel-equipped asphalt pavers offer superior jobsite mobility for applications that require a lot of paver movement and relocation.

Model	Gross Power	Standard Paving Range	Operating Weight - With SE34 VT
AP300F	73.8 HP / 55 kW	1.75 - 3.42 m (5.6' - 11.1')	18078 lb / 8200 kg

Motor Graders

Built with decades of design experience, you'll find the perfect Cat® motor grader for your grading application. With world-class cabs, advanced hydraulics, control-type options and technology options, you'll complete your grading projects on time and at a lower cost.

Model
120 / 120 AWD
140 / 140 AWD
140 / 140 AWD - LVR
140 GC / 140 GC AWD
150 / 150 AWD
160 / 160 AWD
14
16
18
24

Coal Bowl Scrapers

Cat® coal bowl scrapers use a high volume bowl designed to help the power generation industry move low density loose coal within the power generation facility.

Model	Flywheel Power - Tractor/Scraper	Scraper Capacity - Heaped	Top Speed - Loaded
637K (TIER 2/STAGE II)	425 kW (570 hp)/216 kW (290 hp)	50 yd³ / 38 m³	34.7 mile/h / 55.8 km/h
637K	425 kW (570 hp)/216 kW (290 hp)	50 yd³ / 38 m³	34.7 mile/h / 55.8 km/h
657G	447 kw (600 hp) / 337 kW (451 hp)	73 yd³ / 56 m³	33 mile/h / 53 km/h

Elevating Scrapers

Cat® elevating scrapers are a self-loading hauling system with the added ability to mix and homogenize material. Elevator scrapers also excel at fine finish grading work.

Model	Flywheel Power - Tractor/Scraper	Scraper Capacity - Heaped	Top Speed - Loaded
623K	304 kW (407 hp)	23 yd³ / 17.6 m³	33.5 mile/h / 53.9 km/h

Track Loaders

Save time and money with one machine for land clearing, digging, grading, truck loading, slope work and more. Crawler loaders have less ground pressure and better traction letting you start jobs earlier and work longer regardless of ground conditions. Waste Handler, Ship Hold and Partial Steel Mill configurations are available.

Model	Flywheel Power	Operating Weight	Capacity - General Purpose
973K	275 HP / 205 kW	63900 lb / 28985 kg	4.2 yd³ / 3.2 m³

Large Dozers

Cat® large dozers are designed for tough working conditions. Elevated sprockets increase productivity, simplify maintenance, reduce downtime with modular components and raise final drives and associated power train components out of the work environment. Cat mining dozers keep material moving with the reliability and low operating costs.

Model	Engine Model	Flywheel Power	Operating Weight
D8T	Cat C15 ACERT™	354 HP / 264 kW	86900 lb / 39420 kg
D9T WH	Cat® C18	436 HP / 325 kW	110471 lb / 50109 kg

Medium Dozers

Cat® bulldozers help you move more material in less time. Fuel efficiency and features to make service and maintenance easier help you reduce your overall dozer owning and operating costs. Plus, factory integrated GRADE technology features help get work done even faster, from first pass to finish grade.

Model	Engine Model	Operating Weight
D6K2	Cat C4.4	29258 lb / 13271 kg
D6N	Cat C7.1	36943 lb / 16757 kg
D5	Cat C7.1	42263 lb / 19170 kg
D6	Cat C9.3B	50733 lb / 23012 kg
D6 XE	Cat C9.3B	51333 lb / 23285 kg
D7	Cat C9.3B	65644 lb / 29776 kg

Large Wheel Loaders

Cat® Large Wheel Loaders set the standard for optimized productivity, minimizing downtime, enhancing operator comfort, and protecting people on your jobsite through key safety features.

Model	Net Power	Operating Weight
986K	373 HP / 278 kW	98806 lb / 44818 kg
988K	541 HP / 403 kW	112574 lb / 51062 kg
988K Block Handler Arrangement	541 HP / 403 kW	135602 lb / 61508 kg
988K Millyard Arrangement	541 HP / 403 kW	139920 lb / 63600 kg
988K Steel Mill Arrangement	541 HP / 403 kW	112574 lb / 51062 kg
990K	699 HP / 521 kW	178517 lb / 80974 kg
990K Millyard Arrangement	699 HP / 521 kW	202398 lb / 91807 kg
990K Steel Mill Arrangement	699 HP / 521 kW	204693 lb / 92848 kg
994K	1739 HP / 1297 kW	534852 lb / 242605 kg
986K Block Handler Arrangement	373 HP / 278 kW	116688 lb / 52929 kg

Medium Wheel Loaders

From material handling and truck loading, general construction or stockpiling, Cat® medium wheel loaders are ready for your work. Spacious cabs and low effort controls ensure a comfortable and productive environment. Their reliability, durability and versatility result in front loaders that are built for your success.

Model	Operating Weight
950 GC	41554 lb / 18849 kg
950M	42357 lb / 19213 kg
962M	44591 lb / 20226 kg
972 XE	54858 lb / 24890 kg
980	66877 lb / 30344 kg
980 XE	66877 lb / 30344 kg
982	78264 lb / 35510 kg
982 XE	78264 lb / 35510 kg

Wheel Dozers

Cat® wheel dozers offer high production capabilities, along with mobility and versatility. These utility machines are designed for demanding work and are a great choice for applications including surface mining, cleanup, stock piles, road maintenance, reclamation and jobs where travel is required between multiple sites.

Model	Engine Model
824K	Cat® C15
834K	Cat® C18
834K Scoops for Coal & Woodchips	C18 Cat®
844K	C27 Cat®
854K	Cat® C32 ACERT™
814K	C7.1 Cat®
834H Coal Scoop	Cat® C18 ACERT™
834H Wood Chip Scoop	Cat® C18 ACERT™

Medium Excavators

Their size make Cat® mid-size excavators easy to transport to the jobsite. With ample power, exclusive factory-equipped technology, comfortable cabs, simple maintenance and matching Cat attachments, Cat mid-size excavators will help you complete larger projects at a lower cost.

Model	Net Power - ISO 9249	Operating Weight	Maximum Digging Depth
320 GC	146 HP / 109 kW	48300 lb / 21900 kg	22 ft / 6720 mm
320 - Tier 4F / EU Stage V	172 HP / 128.5 kW	49600 lb / 22500 kg	22.1 ft / 6720 mm
323 - Tier 4F / EU Stage V	172 HP / 128.5 kW	54900 lb / 24900 kg	22.1 ft / 6730 mm
325	172 HP / 128.5 kW	62800 lb / 28500 kg	22 ft / 6700 mm
326 - Tier 4F/ EU Stage V	201 HP / 149.8 kW	56400 lb / 25600 kg	22.38 ft / 6820 mm
330 GC	201 HP / 150 kW	67900 lb / 30800 kg	23.8 ft / 7260 mm
330 - Tier 4F/ EU Stage V	273 HP / 203.7 kW	69200 lb / 31400 kg	23.9 ft / 7240 mm
335	273 HP / 203.7 kW	77000 lb / 34900 kg	22.11 ft / 6990 mm

Waste Handling Dozers

Cat Waste Handling Arrangements for Dozers include guards for the radiator, engine compartment, crankcase (belly), and tilt cylinder lines provide protection for critical machine components under harsh waste handling environments.

Model	Engine Model	Flywheel Power	Operating Weight
D6T WH	Cat C9.3 ACERT™	245 HP / 183 kW	56063 lb / 25430 kg
D7E WH	Cat® C9.3 ACERT™	251 HP / 187 kW	71455 lb / 32411 kg
D6N WH	Cat C7.1 ACERT™	182 HP / 136 kW	40818 lb / 18515 kg
D8T WH	Cat C15 ACERT™	335 HP / 252 kW	86710 lb / 39366 kg

Open Bowl Scrapers

Cat® open bowl wheel-tractor scrapers are a high production hauling solution with a broad material appetite. Open bowl scrapers are available as a self-loading, push-loaded or push-pull hauling system.

Model
621K
627K
631K
637K
657
