S3050 Rotating Scrap & Demolition Shear

Heavy Equipment

S3050 Rotating Scrap & Demolition Shear

Apex Force
340 ton-f / 3029 kN
Cutting Circuit - Maximum Flow
92 gal/min / 350 l/min
Cutting Circuit - Maximum Relief Pressure
5075 psi / 35000 kPa

Cat® Scrap and Demolition Shears are designed to make you money. An innovative, robust design and fast cycle times provide the production and reliability you need to be profitable. Cat shears are efficient and can handle everything from structural steel to mixed scrap. Cat shears are designed to get the job done.

alt 1
Shears Key Features
Product Specifications
Apex Force 340 ton-f / 3029 kN
Boom Mounted – Maximum 40 tons
Boom Mounted – Minimum 24 tons
Cutting Circuit - Maximum Flow 92 gal/min / 350 l/min
Cutting Circuit - Maximum Relief Pressure 5075 psi / 35000 kPa
Cycle Time - Close 3.3 s
Cycle Time - Open 4 s
Height 58 in / 1480 mm
Jaw Depth 25 in / 635 mm
Jaw Opening 26.8 in / 681 mm
Jaw Width - Fixed 19 in / 476 mm
Jaw Width - Moving 5 in / 135 mm
Length 176 in / 4475 mm
Rotation Circuit - Maximum Flow 10.6 gal/min / 40 l/min
Rotation Circuit - Maximum Relief Pressure 2030 psi / 14000 kPa
Stick Mounted – Maximum 60 tons
Stick Mounted – Minimum 42 tons
Throat Force 741 ton-f / 6592 kN
Tip Force 187 ton-f / 1667 kN
Weight - Boom Mount 11201 lb / 5080 kg
Weight - Stick Mount 10650 lb / 4830 kg
Width 42 in / 1060 mm

Large Excavators

Cat large excavators range from 36 to 90 tons (36,000 to 90,000 kg). Their power, speed, and fuel efficiency make them exceptional choices for bulk earthmoving and heavy lifting applications. With powerful, yet efficient engines, advanced hydraulic systems, exclusive Cat Connect Technology, and a variety of Cat attachments, Cat large excavators can help you complete your large-scale projects on time and within budget.

Model Engine Model Net Flywheel Power Operating Weight
349F L Cat C13 ACERT 417 HP / 311 kW 107145 lb / 48600 kg
352F Cat C13 ACERT 417 HP / 311 kW 112200 lb / 50900 kg

Medium Excavators

Cat mid-size excavators range from 20 to 35 tons (20,000 to 35,000 kg). Their size makes them easy to transport to the jobsite, and their power, exclusive Cat Connect Technology, and Cat attachments help you complete larger projects at a lower cost.

Model Engine Model Net Flywheel Power Operating Weight
325F L Cat C4.4 ACERT 161 HP / 120 kW 57100 lb / 25900 kg
326F L (2017) Cat C7.1 ACERT 200 HP / 149 kW 66250 lb / 30050 kg
335F L Cat® C7.1 ACERT™ 200 HP / 149 kW 84170 lb / 38180 kg
