Off-Highway Trucks Bare Chassis

Cat® bare chassis off-highway trucks provide the custom solution for specialized applications such as water trucks using the proven components of Cat off-highway trucks and the support of Caterpillar and your Cat dealer.

Model	LRC Bare Chassis Weight without Hoist	Tractor ROPS	Nominal Water Tank Capacity
770 Bare Chassis	54357 lb / 24656 kg	77430 lb / 35122 kg	9000 gal (US) / 34000 l

Wheel Excavators

Cat® wheeled excavators have the mobility, speed, power, and reliability to be the most versatile machine in your fleet. They help you take on a variety of challenges every day, and at a lower cost.

Model	Engine Power - ISO 14396	Operating Weight Maximum
M314	134 HP / 100 kW	39683 lb / 18000 kg
M315	148 HP / 110 kW	39680 lb / 18000 kg
M316	148 HP / 110 kW	36400 lb / 16510 kg
M318	174 HP / 129 kW	43980 lb / 19950 kg
M319	174 HP / 129.4 kW	46407 lb / 21050 kg
M320	174 HP / 129.4 kW	46740 lb / 21200 kg
M322	174 HP / 129 kW	52911 lb / 24000 kg

Small Excavators

Cat small excavators are perfect for smaller jobs and applications with space constraints. Powered by fuel-efficient engines and advanced hydraulic systems, our small excavators offer exclusive Cat technology and a variety of matching Cat attachments to help you complete your work on time at a low cost per hour.

Model	Net Power - ISO 9249	Operating Weight	Maximum Digging Depth
313F L	92 HP / 68 kW	33080 lb / 15000 kg	19.8 ft / 6040 mm
315F L	97 HP / 72 kW	37794 lb / 17140 kg	19.5 ft / 5950 mm
313 GC	73 HP / 54.3 kW	30400 lb / 13800 kg	19.8 ft / 6040 mm
313	108 HP / 80.9 kW	30400 lb / 13800 kg	19.8 ft / 6040 mm
315	108 HP / 80.9 kW	34000 lb / 15400 kg	19.6 ft / 5990 mm

Telehandlers

Telehandlers from Caterpillar

Model	Rated Load Capacity	Maximum Lift Height	Engine Model
TL1255D	12000 lb / 5443 kg	54.6 ft / 16600 mm	Cat® C4.4 ACERT™*

Three Axle Articulated Trucks

Cat® articulated trucks haul a wide spectrum of material in a variety of applications and ground conditions. Simple operation and automotive style comfort along with combined service points and extended service intervals mean these dump trucks let you focus on your work spending less time and money on servicing.

Model	Engine Model	Rated Payload	Heaped (SAE 2:1)
725C2	Cat C9.3	26.5 ton (US) / 24 ton (US)	19.6 yd³ / 15 m³
725	Cat C9.3	26.5 ton (US) / 24 t	19.6 yd³ / 15 m³
740 EJ	Cat® C18	42 ton (US) / 38 t	30.1 yd³ / 23 m³
745	Cat C18	45.2 t / 41 t	32.7 yd³ / 25 m³

Cold Planer

Cat cold planers remove worn or deteriorated pavement to a specified grade and slope and leave a textured surface that can be immediately opened to traffic or overlayed with new asphalt.

Model	Milling Width	Rated Power	Operating Weight
PM310 Track Undercarriage (Tier 4/Stage V)	39.4 in / 1000 mm	343 HP / 256 kW	46770 lb / 21215 kg
PM312 Track Undercarriage (Tier 4/Stage V)	48.2 in / 1225 mm	343 HP / 256 kW	47407 lb / 21503 kg
PM313 Track Undercarriage (Tier 4/Stage V)	51.2 in / 1300 mm	343 HP / 256 kW	47522 lb / 21556 kg
PM620	79.1 in / 2010 mm	636 HP / 474 kW	73480 lb / 33330 kg
PM622	88 in / 2235 mm	636 HP / 474 kW	74737 lb / 33900 kg
PM820	79.1 in / 2010 mm	806 HP / 601 kW	79653 lb / 36130 kg
PM822	88 in / 2235 mm	806 HP / 601 kW	80910 lb / 36700 kg
PM825	98.6 in / 2505 mm	806 HP / 601 kW	82673 lb / 37500 kg

Landfill Compactors

Cat® landfill compactors have enhanced features with additional guarding and attention to placement of components to ensure you get the most durable landfill compactor.

Model	Operating Weight	Gross Power	Net Power
826K	90207 lb / 40917 kg	435 HP / 324 kW	405 HP / 302 kW

Soil Compactors

The purpose built Cat® four wheel drive soil compactors maximize soil density through a tamping wheel tip design, machine weight impact and higher speeds for greater penetration.

Model	Engine Model	Net Power	Operating Weight
825K	C15 Cat	405 HP / 302 kW	78326 lb / 35528 kg

Tandem Vibratory Rollers

Cat Tandem Vibratory Rollers are available in a range of sizes and configurations to meet any application. Large double-drums are simple to set up for maximum compaction efficiency on any type of mix.

Model	Standard Compaction Width
CB1.7	35 in / 900 mm
CB1.8	39 in / 1000 mm
CB13	79 in / 2000 mm
CB15	84 in / 2130 mm
CB16	84 in / 2130 mm
CCS9 Combination Asphalt Compactor	84 in / 2134 mm

Pneumatic Rollers

Cat Pneumatic Rollers are ideal for applications like wear courses and binder courses as well as compaction of natural soils and materials with lime or cement.

Model
CW34
CW16 9-Wheel
CW16 11-Wheel

Vibratory Soil Compactors

Cat Vibratory Soil Compactors are durable and reliable. They offer high compaction performance, speed and gradeability to maximize productivity on a wide range of applications.

Model	Gross Power
CP34	74.4 HP / 55.5 kW
CS34	74 HP / 55 kW
CP44B	100.6 HP / 75 kW
CS44B	100.6 HP / 75 kW
CP54B	131 HP / 98 kW
CS54B	131 HP / 98 kW
CP56B	157 HP / 117 kW
CS56B	157 HP / 117 kW
CS64B	131 HP / 98 kW
CP68B	157 HP / 117 kW
CS68B	157 HP / 117 kW
CP74B	173.7 HP / 129.5 kW
CS74B	173.7 HP / 129.5 kW
CS78B	173.7 HP / 129.5 kW
CP12	159 HP / 118.6 kW
CS12	159 HP / 118.6 kW
CP14	159 HP / 118.6 kW
CS14	159 HP / 118.6 kW
CP16	175.7 HP / 131 kW
CS16	175.7 HP / 131 kW
CS19	175.7 HP / 131 kW

Large Excavators

Their power, speed, and fuel efficiency make Cat® large excavators the right machine for bulk excavation applications. With powerful, yet efficient engines, advanced hydraulic systems, factory equipped technology, and matching attachments, these machines will help you complete your large-scale projects on time and within budget.

Model	Net Power - ISO 9249	Operating Weight	Maximum Digging Depth
374 - Tier 4	484 HP / 361 kW	162900 lb / 73890 kg	28.1 ft / 8570 mm
352	443 HP / 330 kW	107800 lb / 48900 kg	26.11 ft / 8210 mm

Motor Graders

Built with decades of design experience, you'll find the perfect Cat® motor grader for your grading application. With world-class cabs, advanced hydraulics, control-type options and technology options, you'll complete your grading projects on time and at a lower cost.

Model	Operating Weight - Typically Equipped
120 / 120 AWD	16271 lb / 35871 kg
140 / 140 AWD -Tier 4 / Stage 5	42647 lb / 19344 kg
140 / 140 AWD LVR - Tier 4 / Stage 5	20236 lb / 44613 kg
140 GC / 140 GC AWD - Tier 4 / Stage 5	38912 lb / 17650 kg
150 / 150 AWD - Tier 4 / Stage 5	43950 lb / 19935 kg
160 / 160 AWD - Tier 4 / Stage 5	45547 lb / 20660 kg
14	57250 lb / 25968 kg
16	71454 lb / 32411 kg
18	74324 lb / 33713 kg
24	165314 lb / 74985 kg

Road Reclaimer

Cat Road Reclaimers Pulverize & Stabilize Deteriorated Roadways

Model	Maximum Operating Weight	Cutting/Mixing Width	Gross Power
RM500B	62611 lb / 28400 kg	96 in / 2438 mm	546 HP / 407 kW

Coal Bowl Scrapers

Cat® coal bowl scrapers use a high volume bowl designed to help the power generation industry move low density loose coal within the power generation facility.

Model	Flywheel Power - Tractor/Scraper	Scraper Capacity - Heaped	Top Speed - Loaded
637K	425 kW (570 hp)/216 kW (290 hp)	50 yd³ / 38 m³	34.7 mile/h / 55.8 km/h

Elevating Scrapers

Cat® elevating scrapers are a self-loading hauling system with the added ability to mix and homogenize material. Elevator scrapers also excel at fine finish grading work.

Model	Flywheel Power - Tractor/Scraper	Scraper Capacity - Heaped	Top Speed - Loaded
623K	304 kW (407 hp)	23 yd³ / 17.6 m³	33.5 mile/h / 53.9 km/h

Track Loaders

Save time and money with one machine for land clearing, digging, grading, truck loading, slope work and more. Crawler loaders have less ground pressure and better traction letting you start jobs earlier and work longer regardless of ground conditions. Waste Handler, Ship Hold and Partial Steel Mill configurations are available.

Model	Flywheel Power	Operating Weight	Capacity - General Purpose
973K	275 HP / 205 kW	63900 lb / 28985 kg	4.2 yd³ / 3.2 m³

Medium Dozers

Cat® bulldozers help you move more material in less time. Fuel efficiency and features to make service and maintenance easier help you reduce your overall dozer owning and operating costs. Plus, factory integrated GRADE technology features help get work done even faster, from first pass to finish grade.

Model	Engine Model	Power - Net	Operating Weight
D6K2	Cat C4.4	130 HP / 97 kW	29258 lb / 13271 kg
D5	Cat C7.1	170 HP / 127 kW	42263 lb / 19170 kg
D6	Cat C9.3B	215 HP / 161 kW	50733 lb / 23012 kg
D6 XE	Cat C9.3B	215 HP / 161 kW	51333 lb / 23285 kg
D7	Cat C9.3B	265 HP / 197 kW	65644 lb / 29776 kg

Medium Wheel Loaders

From material handling and truck loading, general construction or stockpiling, Cat® medium wheel loaders are ready for your work. Spacious cabs and low effort controls ensure a comfortable and productive environment. Their reliability, durability and versatility result in front loaders that are built for your success.

Model	Operating Weight
950 GC	41554 lb / 18849 kg
972 XE	54858 lb / 24890 kg
980	66877 lb / 30344 kg
980 XE	66877 lb / 30344 kg
982	78264 lb / 35510 kg
982 XE	78264 lb / 35510 kg

Wheel Dozers

Cat® wheel dozers offer high production capabilities, along with mobility and versatility. These utility machines are designed for demanding work and are a great choice for applications including surface mining, cleanup, stock piles, road maintenance, reclamation and jobs where travel is required between multiple sites.

Model	Engine Model	Net Power - ISO 9249	Stroke
824K	Cat® C15	405 HP / 302 kW	6.7 in / 171.4 mm

Medium Excavators

Their size make Cat® mid-size excavators easy to transport to the jobsite. With ample power, exclusive factory-equipped technology, comfortable cabs, simple maintenance and matching Cat attachments, Cat mid-size excavators will help you complete larger projects at a lower cost.

Model	Net Power - ISO 9249	Operating Weight	Maximum Digging Depth
320 GC - Tier 4 / Stage V	146 HP / 109 kW	48500 lb / 22000 kg	22 ft / 6720 mm
320 - Tier 4 / Stage V	172 HP / 128.5 kW	49800 lb / 22600 kg	22 ft / 6720 mm
323 - Tier 4 / Stage V	172 HP / 128.5 kW	55100 lb / 25000 kg	22.1 ft / 6730 mm
325 - Tier 4 / Stage V	172 HP / 128.5 kW	62800 lb / 28500 kg	22 ft / 6700 mm
326 - Tier 4 / Stage V	201 HP / 149.8 kW	56400 lb / 25600 kg	22.4 ft / 6820 mm
330 GC - Tier 4 / Stage V	201 HP / 150 kW	68100 lb / 30900 kg	23.8 ft / 7260 mm
330 - Tier 4 / Stage V	273 HP / 203.7 kW	69200 lb / 31400 kg	23.9 ft / 7240 mm
335 - Tier 4 / Stage V	273 HP / 203.7 kW	77000 lb / 34900 kg	22.9 ft / 6990 mm

Open Bowl Scrapers

Cat® open bowl wheel-tractor scrapers are a high production hauling solution with a broad material appetite. Open bowl scrapers are available as a self-loading, push-loaded or push-pull hauling system.

Model
621K
627K
631K
637K
657
