G324 WH Demolition & Sorting Grapple: 587-8985
- Grapple Area
- 1.96 yd³ / 1500 l
- Weight
- 4418 lb / 2004 kg
- Overall Width (Jaws Open)
- 106.3 in / 2700 mm
Cat® Demolition & Sorting Grapples are designed for fast, productive material handling. Capable of high-volume, production loading and precise sorting, to enhance the productivity and efficiency of your operation. The grapples can handle anything from primary and secondary demolition to recycling to get the job done.
Demolition & Sorting Grapples Key Features and Benefits
Demolition & Sorting Grapples for Tracked Excavators Technical Specifications
Demolition & Sorting Grapples for Wheeled Excavators Technical Specifications
Demolition & Sorting Grapples for Material Handlers Technical Specifications
Demolition & Sorting Grapple Product Brochure
| Product Specifications | |
|---|---|
| Grapple Area | 1.96 yd³ / 1500 l |
| Weight | 4418 lb / 2004 kg |
| Machine Class | 23-30 Ton Excavators |
| Overall Width (Jaws Open) | 106.3 in / 2700 mm |
| Overall Width (Jaws Closed) | 66.54 in / 1690 mm |
| Overall Height (Jaws Open) | 61.97 in / 1574 mm |
| Overall Height (Jaws Closed) | 72.6 in / 1844 mm |
| Shell Type Options | Perforated |
Medium Excavators
| Model | Net Power - ISO 9249 | Operating Weight | Maximum Digging Depth |
|---|---|---|---|
| 323 | 172 hp / 128.5 kW | 55100 lb / 25000 kg | 22.1 ft / 6730 mm |
| 326 | 201 hp / 149.8 kW | 56400 lb / 25600 kg | 22.4 ft / 6820 mm |
| 330 | 273 hp / 203.7 kW | 69200 lb / 31400 kg | 23.9 ft / 7240 mm |
| 335 | 273 hp / 203.7 kW | 77000 lb / 34900 kg | 22.9 ft / 6990 mm |
