BA30 Hydraulic, 24V, Polypropylene/Wire
- Overall Width
- 126 in / 3200 mm
- Sweeping Width
- 118.1 in / 3000 mm
- Brush Diameter
- 36 in / 915 mm
Used for clearing parking lots, industrial plants, mill yards, airport runways, streets, driveways and lanes.
| Product Specifications | |
|---|---|
| Overall Width | 126 in / 3200 mm |
| Sweeping Width | 118.1 in / 3000 mm |
| Brush Diameter | 36 in / 915 mm |
| Required Hydraulics | Standard Flow |
| Height | 59.8 in / 1520 mm |
| Length | 64.2 in / 1630 mm |
| Weight | 1124.4 lb / 510 kg |
| Optimal Hydraulic Flow | 42-300 L/min (11-80 gpm) |
| Optimal Hydraulic Pressure | 150-260 bar (2176-3771 psi) |
| Motor Displacement | 18.9 in³/rev / 310 cm³/rev |
| Brush Speed at Maximum Flow | 303 RPM |
| Sweeping Width - Angled (± 30 Degrees) | 102.4 in / 2600 mm |
| Overall Width - Angled (± 30 Degrees) | 110.2 in / 2800 mm |
| Drive Method | Direct Drive |
| Interface Type | Requires Hook Group |
| Voltage | 24V |
| Voltage Type | 24V |
