TRS8, Pin On (Pin Grabber) / S50, 10 Ton Mini Excavators
- Weight
- 712.5 lb / 323.2 kg
- Overall Height
- 37.6 in / 956 mm
- Length
- 26 in / 660 mm
Cat® Tiltrotators help you maneuver obstacles in your work area without the need for repositioning your machine.
| Product Specifications | |
|---|---|
| Machine Class | 10 Ton Mini Excavators |
| Weight | 712.5 lb / 323.2 kg |
| Interface Options: Top-Bottom | Pin On (Pin Grabber Coupler) / S50 Coupler |
| Overall Height | 37.6 in / 956 mm |
| Length | 26 in / 660 mm |
| Overall Width | 26.7 in / 678 mm |
| Rotation Speed | 7 Seconds per 1 full rotation |
| Tilt Angle Range | 40° Left/Right |
| Maximum Bucket Capacity | 17.7 ft³ / 500 l |
| Maximum Bucket Width | 59.1 in / 1500 mm |
| Optimal Hydraulic Flow | 45-75 L/min (12-20 gpm) |
| Maximum Operating Pressure | 3625.9 psi / 25000 kPa |
| Required Hydraulics | 1st Auxiliary |
| Tilting Torque | 19545.4 lb/ft / 26500 N·m |
| Turning Torque | 2876.5 lb/ft / 3900 N·m |
| Compatibility | Only compatible with the following Mini Excavator model serial number prefixes: 310 (GWT 1 & up) |
