2337 mm (92 in)

Heavy Equipment

2337 mm (92 in)

Overall Width
92 in / 2337 mm
Width - Fully Angled
81 in / 2049 mm
Blade Height
24 in / 619 mm

Product Specifications
Overall Width 92 in / 2337 mm
Width - Fully Angled 81 in / 2049 mm
Blade Height 24 in / 619 mm
Cutting Edge Thickness 0.63 in / 16 mm
Length 40 in / 1028 mm
Maximum Blade Angle - Right/Left of Center ±30 degrees
Required Hydraulic Flow 49-125 L/min (13-33 gpm)
Tilt ±10 degrees
Weight 1164 lb / 528 kg
Optimum Hydraulic Pressure 206-311 bar (3000-4500 psi)
Required Hydraulics Standard Flow
