Heavy Equipment
PC310B
- Working Width
- 39 in / 1000 mm
- Maximum Cutting Depth
- 5 in / 130 mm
- Overall Width
- 73 in / 1858 mm
High speed drum and conical bits quickly remove asphalt and concrete prior to resurfacing.
High speed drum and conical bits quickly remove asphalt and concrete prior to resurfacing.
| Product Specifications | |
|---|---|
| Optimal Hydraulic Flow | 125 L/min (33 gpm) |
| Optimal Hydraulic Pressure | 280 bar (4000 psi) |
| Maximum Cutting Depth | 5 in / 130 mm |
| Required Hydraulics | High Flow XPS |
| Overall Width | 73 in / 1858 mm |
| Overall Length | 45 in / 1140 mm |
| Overall Height | 38 in / 965 mm |
| Weight | 2130 lb / 1050 kg |
| Drum Speed | 166 rpm |
| Optional Drum Widths/Depths | n/a |
| Tilt Angle Range +/- | 6.5 degrees |
| Side Shift Travel | 26 in / 650 mm |
| Conical Bits | 78 |
| Working Width | 39 in / 1000 mm |
| Model | Maximum Gross Power | Operating Weight | Bucket Capacities |
|---|---|---|---|
| 906M | 73 HP / 54.6 kW | 12346 lb / 5600 kg | 0.75 m³-1.2 m³ (1.0 yd³-1.6 yd³) |
| 907M | 73 HP / 54.6 kW | 12677 lb / 5750 kg | 0.75 m³-1.2 m³ (1.0 yd³-1.6 yd³) |
| 908M | 73 HP / 54.6 kW | 14032 lb / 6365 kg | 0.9 m³-1.5 m³ (1.2 yd³-2.0 yd³) |
| Model | Engine Model | Net Flywheel Power | Rated Operating Capacity |
|---|---|---|---|
| 246D | Cat C3.3B DIT (turbo) | 72.9 HP / 54.4 kW | 2150 lb / 975 kg |
| 262D | Cat C3.3B DIT (Turbo) | 72.9 HP / 54.4 kW | 2700 lb / 1225 kg |
| 272D2 | Cat C3.8 DIT (turbo) | 95 HP / 71 kW | 3400 lb / 1542 kg |
| 272D2 XHP | Cat C3.8 DIT (turbo) | 106 HP / 79 kW | 3650 lb / 1656 kg |
