HM112

Overall Width
59.8 in / 1518 mm
Working Width
48.8 in / 1240 mm
Length
48 in / 1219 mm

High-performance cutting and mulching of vegetation and overgrowth.

Loan Calculator Credit Application
Build & Quote
alt 1
Cat® Mulchers Brochure
Product Specifications
Overall Width 59.8 in / 1518 mm
Working Width 48.8 in / 1240 mm
Length 48 in / 1219 mm
Overall Height 50.4 in / 1281 mm
Weight 1682.1 lb / 763 kg
Drive Method V-Belt
Motor Axial Piston Dual Speed
Required Hydraulics Standard Flow
Optimal Hydraulic Flow 60-69 L/min (16-18 gpm)
Optimal Hydraulic Pressure 200-230 bar (2900-3336 psi)
Drum Speed 2670-3070 RPM
Fixed Teeth per Drum 30
Maximum Cutting Diameter 7.9 in / 200 mm
Maximum Cutting Depth 2.8 in / 70 mm

Skid Steer Loaders

Built for tough work, Cat® skid steer loaders deliver reliability, durability, and efficient operation. These versatile wheeled machines are well suited for general construction, landscaping, agriculture, snow removal and other applications. Cat skid steer loaders are available in a wide variety of sizes and loading capabilities, and with a vast array of attachments, these machines have a wide variety of jobsite applications.

Model Gross Power - SAE J1995 Rated Operating Capacity Operating Weight
226D3 67.1 hp / 50.1 kW 1550 lb / 705 kg 5849 lb / 2653 kg
232D3 67.1 hp / 50.1 kW 1900 lb / 865 kg 6514 lb / 2955 kg

Compact Track Loaders

Cat® compact track loaders feature a steel embedded track and steel undercarriage components for maximum life in applications where underfoot conditions may not be ideally suited for a skid steer loader. These versatile machines are well suited for general construction, landscaping, agriculture, snow removal and other applications. With the vast array of attachments available from Caterpillar, these machines can do it all.

Model Gross Power - SAE J1995 Rated Operating Capacities - 35% Tipping Load Operating Weight
239D3 67.1 hp / 50.1 kW 1530 lb / 695 kg 7434 lb / 3372 kg
249D3 67.1 hp / 50.1 kW 1740 lb / 790 kg 7831 lb / 3552 kg
