D6N WH
- Flywheel Power
- 182 hp / 136 kW
- Operating Weight
- 40818 lb / 18515 kg
- Bore
- 4.1 in / 105 mm
From pushing trash to spreading cover, and cell construction to closing, Cat® Waste Handlers are designed and manufactured from the frame up to take on the demands of landfill work.
| Engine | |
|---|---|
| Engine Model | Cat C7.1 ACERT™ |
| Flywheel Power | 182 hp / 136 kW |
| Bore | 4.1 in / 105 mm |
| Stroke | 5.3 in / 135 mm |
| Displacement | 433 in³ / 7.1 l |
| Net Power - 1,800 rpm - ISO 9249/SAE J1349 (DIN) | 168 hp / 124 kW |
| Net Power - Maximum - ISO 14396 at 2,200 rpm | 178 hp / 133 kW |
| Net Power - 1,800 rpm - ISO 9249/SAE J1349 | 166 hp / 124 kW |
| Net Power - Maximum - SAE J1995 at 2,200 rpm | 182 hp / 136 kW |
| Note (1) | All non road Tier 4, Stage IIIB and IV, and Korea Tier 4 Final diesel engines are required to use only Ultra Low Sulfur Diesel (ULSD) fuels containing 15 ppm (EPA), 10 ppm (EU) (mg/kg) sulfur or less. Biodiesel blends up to B20 (20% blend by volume) are acceptable when blended with 15 ppm (mg/kg) sulfur or less ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214). Cat DEO-ULS™ or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specification are required. Consult your OMM for further machine specific fuel recommendations. |
| Emissions | Tier 4 Final/Stage IV/Korea Tier 4 Final |
| Note (2) | Diesel Exhaust Fluid (DEF) used in Cat Selective Catalytic Reduction (SCR) systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241. |
| Net Power - Maximum - ISO 14396 (DIN) at 2,200 rpm | 180 hp / 133 kW |
| Note (3) | The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.6 kg of refrigerant which has a CO2 equivalent of 2.288 metric tonnes. |
| Weights | |
|---|---|
| Operating Weight | 40818 lb / 18515 kg |
| Operating Weight - LGP Waste Handler | 44749 lb / 20298 kg |
| Operating Weight - XL Waste Handler | 40818 lb / 18515 kg |
| Shipping Weight - LGP Waste Handler | 43642 lb / 19796 kg |
| Shipping Weight - XL Waste Handler | 40029 lb / 18157 kg |
| Dimensions - LGP | |
|---|---|
| Height - Grouser | 2.2 in / 57 mm |
| Track Gauge | 85 in / 2160 mm |
| Length - Basic Tractor - With Drawbar* | 166.2 in / 4222 mm |
| Ground Clearance | 18.8 in / 477 mm |
| Length - Track on Ground | 122.7 in / 3110 mm |
| Width - Tractor - Without Trunnions | 118 in / 3000 mm |
| Machine Height - Grouser Tip - Exhaust Stack | 126.9 in / 3222 mm |
| Note | *Add 957 mm (37.7 in) to length of basic tractor (with drawbar) with ripper (with tip at ground line). |
| Dimensions - XL | |
|---|---|
| Width - Tractor - Without Trunnions | 98.4 in / 2500 mm |
| Machine Height - Grouser Tip - Exhaust Stack | 122.4 in / 3108 mm |
| Ground Pressure | 6.7 psi / 46.1 kPa |
| Track Gauge | 74.4 in / 1890 mm |
| Ground Clearance | 14.3 in / 364 mm |
| Height - Grouser | 2.6 in / 66 mm |
| Length - Basic Tractor - With Drawbar* | 157.3 in / 3995 mm |
| Length - Track on Ground | 101.6 in / 2581 mm |
| Note | *Add 1185 mm (46.7 in) to length of basic tractor (with drawbar) with SU blade added. Add 957 mm (37.7 in) to length of basic tractor (with drawbar) with ripper (with tip at ground line). |
| Product Specifications | |
|---|---|
| Ground Pressure | 4.5 psi / 31.2 kPa |
| Blades - Capacity (SAE J1265) | |
|---|---|
| XL SU | 5.6 yd³ / 4.3 m³ |
| LGP VPAT | 5.1 yd³ / 3.9 m³ |
| LGP VPAT - Landfill* | 7.39 yd³ / 5.65 m³ |
| Note | *Blade capacity with trash rack. |
| XL VPAT Landfill* | 8.29 yd³ / 6.34 m³ |
| XL VPAT | 4.3 yd³ / 3.3 m³ |
| Blades - Width - Over End Bits | |
|---|---|
| LGP VPAT - Landfill* | 12.89 ft / 3929 mm |
| XL SU | 10.33 ft / 3154 mm |
| XL VPAT Landfill* | 10.23 ft / 3120 mm |
| XL VPAT | 10.75 ft / 3272 mm |
| LGP VPAT | 13.38 ft / 4080 mm |
| Note | *Blade capacity with trash rack. |
| Transmission | |
|---|---|
| 0.5 Reverse | 1.9 mile/h / 3.1 km/h |
| 1.5 Forward | 2.7 mile/h / 4.4 km/h |
| 2.5 Forward | 4.7 mile/h / 7.5 km/h |
| 0.7 Forward | 1.7 mile/h / 2.8 km/h |
| 1.7 Reverse | 3.7 mile/h / 6 km/h |
| 1.7 Forward | 3 mile/h / 4.9 km/h |
| 1.5 Reverse | 3.4 mile/h / 5.4 km/h |
| 0.5 Forward | 1.6 mile/h / 2.5 km/h |
| 2.5 Reverse | 5.9 mile/h / 9.5 km/h |
| 2.7 Forward | 5.2 mile/h / 8.3 km/h |
| 0.7 Reverse | 2.1 mile/h / 3.4 km/h |
| 2.7 Reverse | 6.5 mile/h / 10.5 km/h |
| 1.0 Forward | 2.1 mile/h / 3.3 km/h |
| 2.0 Forward | 3.6 mile/h / 5.8 km/h |
| 3.0 Forward | 6.1 mile/h / 9.8 km/h |
| 1.0 Reverse | 2.5 mile/h / 4.1 km/h |
| 2.0 Reverse | 4.4 mile/h / 7.1 km/h |
| 3.0 Reverse | 7.6 mile/h / 12.2 km/h |
