HM416

Overall Width
74.1 in / 1882 mm
Working Width
58.6 in / 1488 mm
Length
53.3 in / 1355 mm

High-performance cutting and mulching of vegetation and overgrowth.

Loan Calculator Credit Application
Build & Quote
alt 1
Cat® Mulchers Brochure
Product Specifications
Overall Width 74.1 in / 1882 mm
Working Width 58.6 in / 1488 mm
Length 53.3 in / 1355 mm
Overall Height 58.3 in / 1481 mm
Weight 2960.8 lb / 1343 kg
Drive Method Polychain Belt
Motor Axial Piston Dual Speed
Required Hydraulics XHP / XE
Optimal Hydraulic Flow 135-155 L/min (36-41 gpm)
Optimal Hydraulic Pressure 200-350 bar (2900-5077 psi)
Drum Speed 1900-2200 RPM
Fixed Teeth per Drum 34
Maximum Cutting Diameter 7.9 in / 200 mm
Maximum Cutting Depth 4.1 in / 105 mm

Skid Steer Loaders

Built for tough work, the Cat® Skid Steer Loaders deliver reliability, durability, and efficient operation.

Model Gross Power - SAE J1995 Rated Operating Capacity Operating Weight
272D3 XE 110 HP / 82 kW 3700 lb / 1680 kg 9573 lb / 4342 kg

Compact Track Loaders

Cat® Compact Track Loaders feature a steel embedded track and steel undercarriage components for maximum life in applications where maintenance, operator technique and underfoot conditions may not be ideally suited for a Multi Terrain Loader or Skid Steer Loader.

Model Gross Power - SAE J1995 Rated Operating Capacities - 35% Tipping Load Operating Weight
299D3 XE 110 HP / 82 kW 3560 lb / 1620 kg 11756 lb / 5333 kg
299D3 XE Land Management 110 HP / 82 kW 4340 lb / 1975 kg 12764 lb / 5790 kg
