HM418
- Overall Width
- 83.5 in / 2122 mm
- Working Width
- 67.2 in / 1707 mm
- Length
- 53.3 in / 1355 mm
High-performance cutting and mulching of vegetation and overgrowth.
| Product Specifications | |
|---|---|
| Overall Width | 83.5 in / 2122 mm |
| Working Width | 67.2 in / 1707 mm |
| Length | 53.3 in / 1355 mm |
| Overall Height | 58.3 in / 1481 mm |
| Weight | 3196.7 lb / 1450 kg |
| Drive Method | Polychain Belt |
| Motor | Axial Piston Dual Speed |
| Required Hydraulics | XHP / XE |
| Optimal Hydraulic Flow | 150-155 L/min (40-41 gpm) |
| Optimal Hydraulic Pressure | 200-278 bar (2900-4061 psi) |
| Drum Speed | 2140-2210 RPM |
| Fixed Teeth per Drum | 38 |
| Maximum Cutting Diameter | 7.9 in / 200 mm |
| Maximum Cutting Depth | 4.1 in / 105 mm |
Skid Steer Loaders
| Model | Gross Power - SAE J1995:2014 | Rated Operating Capacity | Operating Weight |
|---|---|---|---|
| 272D3 XE | 110 hp / 82 kW | 3700 lb / 1680 kg | 9573 lb / 4342 kg |
Compact Track Loaders
| Model | Gross Power - SAE J1995:2014 | Rated Operating Capacities - 35% Tipping Load |
|---|---|---|
| 299D3 XE | 110 hp / 82 kW | 3560 lb / 1620 kg |
| 299D3 XE Land Management | 110 hp / 82 kW | 4340 lb / 1975 kg |
| 275 | 111 hp / 82 kW | 4156 lb / 1885 kg |
| 275 XE | 122 hp / 91 kW | 4205 lb / 1280 kg |
