H45s
- Operating Weight - With Tool
- 551.2 lb / 250 kg
- Energy Class
- 399.8 ft·lbf / 542 J
- Tool Shaft Diameter
- 2 in / 50 mm
Used for demolition and construction applications.
| Product Specifications | |
|---|---|
| Operating Weight - With Tool | 551.2 lb / 250 kg |
| Energy Class | 399.8 ft·lbf / 542 J |
| Machine Class | 1-3 Ton Mini Excavators |
| Tool Shaft Diameter | 2 in / 50 mm |
| Impact Frequency | 780-1800 bpm |
| Minimum Operating Pressure | 1450.4 psi / 10000 kPa |
| Minimum Carrier Weight | 3309.1 lb / 1501 kg |
| Optimal Hydraulic Flow | 25-62 lpm (7-16 gpm) |
| Overall Width | 11.8 in / 300 mm |
| Overall Length | 12.2 in / 311 mm |
| Overall Height | 39.6 in / 1006 mm |
| Height - Without Tool | 29 in / 737 mm |
| Sound Level | 120 dB |
| Mounting Bracket Size | Medium |
Mini Excavators
| Model | Net Power | Operating Weight | Dig Depth |
|---|---|---|---|
| 301.5 | 21 hp / 15.7 kW | 3913 lb / 1775 kg | 100 in / 2540 mm |
| 301.7 CR | 21 hp / 15.7 kW | 4222 lb / 1915 kg | 100 in / 2540 mm |
| 301.8 | 21 hp / 15.7 kW | 4473 lb / 2029 kg | 101.2 in / 2570 mm |
| 302 CR | 21 hp / 15.7 kW | 4987 lb / 2262 kg | 101.2 in / 2570 mm |
| 303 CR | 23.6 hp / 17.6 kW | 7817 lb / 3545 kg | 116.1 in / 2950 mm |
