305 mm (12 in), Pin On
- Width
- 12 in / 305 mm
- Capacity
- 2.8 ft³ / 79 l
- Weight
- 213.8 lb / 97 kg
Designed for general light duty excavation in soft soil or clay.
| Product Specifications | |
|---|---|
| Width | 12 in / 305 mm |
| Capacity | 2.8 ft³ / 79 l |
| Weight | 213.8 lb / 97 kg |
| Base Edge Thickness | 0.8 in / 20 mm |
| Tip Radius | 35.8 in / 909 mm |
| Interface Type | Pin On |
Center-Pivot Backhoe Loaders
| Model | Dig Depth - Standard | Operating Weight - Maximum |
|---|---|---|
| 416 | 14 ft / 4277 mm | 24251 lb / 11000 kg |
| 420 | 14 ft / 4278 mm | 24251 lb / 11000 kg |
| 420 XE | 14 ft / 4278 mm | 24251 lb / 11000 kg |
| 430 | 15.1 ft / 4612 mm | 24251 lb / 11000 kg |
| 440 | 15.5 ft / 4718 mm | 29321 lb / 13300 kg |
| 430F2/430F2 IT | 15.4 ft / 4686 mm | 24251 lb / 11000 kg |
